@李东岳 我看了您提供的PINN算例，感觉目前还没有真正跟of结合起来，是吧？只不过用了of的c++编译环境，可以这么理解么？

@李东岳 谢谢李老师

@李东岳 李老师，http://dyfluid.com/pinn.html ，#include "output.H"这个文件能补充上传么，想研究一下您的完整代码，谢谢

@李东岳 在 OpenFOAM libtorch tutorial step by step 中说：

更新gcc之后你openfoam就编译不了了。那你尝试安装老版本的libtorch吧

李老师，我用的是ubuntu18.04，Of2.4.0，您有推荐的libtorch版本么

@李东岳 就是想把离散点数据

    -17.00000000    -59.58333206      0.00000000    302.77685547
    -17.00000000    -62.50000000      0.00000000    302.77685547
    -17.00000000    -65.41666412      0.00000000    302.77685547
    -17.00000000    -68.33333588      0.00000000    302.77685547
    -17.00000000    -71.25000000      0.00000000    302.77685547
    -17.00000000    -74.16666412      0.00000000    302.77682495
    -17.00000000    -77.08333588      0.00000000    302.77679443
    -17.00000000    -80.00000000      0.00000000    302.77664185

整理成这样：

VARIABLES = "X""Y""Z"
 Nodes=39888, Elements=78526, ZONETYPE=FETriangle
    -17.00000000    -59.58333206      0.00000000    302.77685547
    -17.00000000    -62.50000000      0.00000000    302.77685547
    -17.00000000    -65.41666412      0.00000000    302.77685547
    -17.00000000    -68.33333588      0.00000000    302.77685547
    -17.00000000    -71.25000000      0.00000000    302.77685547
    -17.00000000    -74.16666412      0.00000000    302.77682495
    -17.00000000    -77.08333588      0.00000000    302.77679443
    -17.00000000    -80.00000000      0.00000000    302.77664185
       1       2       3
       3       4       1
       5       6       2
       2       1       5
       7       8       6
       6       5       7

@Prometheus10 谢谢哈，我主要目的是建立节点数据之间的关联，三角形，缩放只能是个视觉上的平面。

用paraview或tecplot那能不能把曲面上的数据投影到一个规则的矩形平面上呢？

大家好，
我目前用starccm做了一个仿真，数据能用tecplot导出ZONETYPE=FEPolygon形式，如何进一步转换成ZONETYPE=FETriangle？
谢谢。

大家好，目前我可以输出温度场的三维数据，比如

我想垂直于z轴做100个等间距垂直切面，在每个切面上对温度求积分并取平均值。
\begin{equation}
\int_{A} T dx dy /A
\end{equation}
然后沿着z轴画出一条温度平均值曲线。

谢谢大家！

@李东岳 非常感谢李老师，终于搞定，能输出数据了，但还需要进一步验证是否正确。差点放弃想升级新版本of。

    volScalarField& summass = const_cast<volScalarField&>(p.mesh().objectRegistry::lookupObject<volScalarField>("summass"));
    const label cellIp = p.cell();
    scalar& PPC = summass.internalField() [cellIp];
    PPC += p.nParticle()*p.mass();

希望对以后需要的朋友有点借鉴作用。特别感谢 @星星星星晴 不厌其烦的解答

@李东岳 李老师，这句命令

volScalarField& summass = p.mesh().objectRegistry::lookupObjectRef<volScalarField>("summass");

又报错了

lnInclude/ParticleCollector.C:745:71: error: ‘class Foam::objectRegistry’ has no member named ‘lookupObjectRef’
     volScalarField& summass = p.mesh().objectRegistry::lookupObjectRef<volScalarField>("summass");

@李东岳 李老师，还是不行

    const volScalarField& summass = p.mesh().objectRegistry::lookupObject<volScalarField>("summass");
    const label cellIp = p.cell();
    summass.internalField() [cellIp] += p.nParticle()*p.mass();

编译出错

lnInclude/ParticleCollector.C:749:38: error: assignment of read-only location ‘(&(& summass)->Foam::GeometricField<Type, PatchField, GeoMesh>::internalField<double, Foam::fvPatchField, Foam::volMesh>())->Foam::Field<double>::<anonymous>.Foam::List<double>::<anonymous>.Foam::UList<T>::operator[]<double>(((Foam::label)cellIp))’
     summass.internalField() [cellIp] += p.nParticle()*p.mass();
                                      ^
lnInclude/ParticleCollector.C: In instantiation of ‘void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&) [with CloudType = Foam::KinematicCloud<Foam::Cloud<Foam::CollidingParcel<Foam::KinematicParcel<Foam::particle> > > >; Foam::ParticleCollector<CloudType>::parcelType = Foam::CollidingParcel<Foam::KinematicParcel<Foam::particle> >; Foam::label = int; Foam::scalar = double; Foam::point = Foam::Vector<double>]’:
parcels/derived/basicKinematicCollidingParcel/makeBasicKinematicCollidingParcelSubmodels.C:53:1:   required from here
lnInclude/ParticleCollector.C:749:38: error: assignment of read-only location ‘(&(& summass)->Foam::GeometricField<Type, PatchField, GeoMesh>::internalField<double, Foam::fvPatchField, Foam::volMesh>())->Foam::Field<double>::<anonymous>.Foam::List<double>::<anonymous>.Foam::UList<T>::operator[]<double>(((Foam::label)cellIp))’
     summass.internalField() [cellIp] += p.nParticle()*p.mass();

@李东岳 还是不行

lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:746:43: error: ‘const InternalField {aka const class Foam::Field<double>}’ has no member named ‘ref’
     scalar& PPC = summass.internalField().ref() [cellIp];
                                           ^
lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:746:43: error: ‘const InternalField {aka const class Foam::Field<double>}’ has no member named ‘ref’
     scalar& PPC = summass.internalField().ref() [cellIp];

@tens 应该是这样的，感觉应该带个指针啥的

@李东岳 李老师，按照下列代码

        const label cellIp = p.cell();
        scalar PPC = summass.internalField() [cellIp];
        PPC += p.nParticle()*p.mass();

编译通过了，也能算了，但是好像没有赋值进去，结果是0

FoamFile
{
    version     2.0;
    format      binary;
    class       volScalarField;
    location    "0.0002";
    object      summass;
}
// * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * //

dimensions      [1 0 0 0 0 0 0];

internalField   uniform 0;

boundaryField
{
    walls
    {
        type            calculated;
        value           uniform 0;
    }
}

@李东岳 我把

const volScalarField& summass = p.mesh().objectRegistry::lookupObject<volScalarField>("summass");

挪到程序前面了，还是同样的错误

@李东岳 编译倒是能通过了，但是运行算例log文件显示错误

[12]
[12]
[12] --> FOAM FATAL ERROR:
[12]
    request for volScalarField summass from objectRegistry region0 failed
    available objects of type volScalarField are

19
(
thermo:mu
thermo:psi
K
h
kappa
air
rho
k
Cp
dpdt
thermo:psi_0
alphat
dQ
p
T
mut
H2O
epsilon
thermo:alpha
)
[12]
[12]
[12]     From function objectRegistry::lookupObject<Type>(const word&) const
[12]     in file /home/chengan/OpenFOAM/OpenFOAM-2.4.0/src/OpenFOAM/lnInclude/objectRegistryTemplates.C at line 198.
[12]

@李东岳 李老师，又出现了之前的问题：

lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:750:31: error: ‘const volScalarField {aka const class Foam::GeometricField<double, Foam::fvPatchField, Foam::volMesh>}’ has no member named ‘internalFieldRef’
         scalar& PPC = summass.internalFieldRef() [cellIp];
                               ^
lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:750:31: error: ‘const volScalarField {aka const class Foam::GeometricField<double, Foam::fvPatchField, Foam::volMesh>}’ has no member named ‘internalFieldRef’
         scalar& PPC = summass.internalFieldRef() [cellIp];

我用grep查了一下，有些函数中用的是internalField()而查不到internalFieldRef()，但如果采用

scalar& PPC = summass.internalField() [cellIp]

错误如下

lnInclude/ParticleCollector.C:750:53: error: binding ‘const double’ to reference of type ‘Foam::scalar& {aka double&}’ discards qualifiers
         scalar& PPC = summass.internalField()[cellIp];

@李东岳 麻烦李老师了。

        const volScalarField& summass = p.mesh().objectRegistry::lookupObject<volScalarField>("summass");
        const label cellIp = p.cell();
        scalar& PPC = summass.internalField()[cellIp];
        PPC += p.nParticle()*p.mass();

还是有错误如下

lnInclude/ParticleCollector.C:750:53: error: binding ‘const double’ to reference of type ‘Foam::scalar& {aka double&}’ discards qualifiers
         scalar& PPC = summass.internalField()[cellIp];

@李东岳 在 如何在src文件中创建标量物理filed并且调用 中说：

p.mesh().objectRegistry::lookupObject<volScalarField>("summass")

lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:750:31: error: ‘const volScalarField {aka const class Foam::GeometricField<double, Foam::fvPatchField, Foam::volMesh>}’ has no member named ‘primitiveFieldRef’
         scalar& PPC = summass.primitiveFieldRef() [cellIp];
                               ^
lnInclude/ParticleCollector.C: In member function ‘virtual void Foam::ParticleCollector<CloudType>::postMove(Foam::ParticleCollector<CloudType>::parcelType&, Foam::label, Foam::scalar, const point&, bool&)’:
lnInclude/ParticleCollector.C:750:31: error: ‘const volScalarField {aka const class Foam::GeometricField<double, Foam::fvPatchField, Foam::volMesh>}’ has no member named ‘primitiveFieldRef’
         scalar& PPC = summass.primitiveFieldRef() [cellIp];

好像是没有 member named ‘primitiveFieldRef’，我用的是of2.4.0
